Description
Process introduction:
The working principle of UV Cylinder Printer is to print the pattern directly on the Cylindrical objects such as cups, bottles. It is widely used for various industries, because of all the patterns can be printed, such as the LOGO or other customized patterns.
So, now UV Flatbed Printer is so popular in the advertising industries.
Firstly
Use a UV DTF Printer to print out
the pattern.
Secondly
Cut the UV DTF sticker after printing.
Thirdly
Stick it on the hard object.
Forthly
Tear off the B film, and the pattern is on the object tightly.
Process advantage:
- No engraving
More convenient and faster, saving time and labor
Simple operation, efficient and stable
- Widely using
Customization of LOGO or pattern for advertising
Eco-friendly
Pattern customization
Printing pattern freelColorful
Accurate color, small color difference
Japan THK silent
linear guide rail
Low operating noise and durable guide rails
Leadshine
Motor
Accurate stepping and accurate printing.
Automatic lamination
Comes with laminating function, no need to purchase additional lamination machine.
Aviation aluminum
Integrated Base and Beam
Material accuracy error is only ±0.02mm
Printer parameters:
| Name | UV Cylinder Printer |
| Equipment Model | KY-H80UV |
| Print head | Epson i1600 * 3pcs |
| Printing Precision | 720dpi-2880dpi |
| Printing Size | Length 0-240mm; Diameter 55-180mm; Taper 12° |
| Pritning Speed | 80s/pc (Full-width printing) |
| Media | Bottles, cups, cans… |
| Ink System | Syphon Positive Pressure |
| Temperature | 15-30℃ |
| Humidity | 30%-70% |
| Power | 1300W |
| Voltage | 220V |
| Size of Machine | L1340mm*W480mm*H730mm |
| Size of Package | L1400mm*W087mm*H830mm |
| Net Weight | 134KG |
| Gross Weight | 160KG |
